Use in high mounting heights that require high efficiencies, horizontal illumination and high vertical illumination. Ideal for manufacturing and warehouse aisles where color is critical.
Housing: Rugged, heavy-duty, die-cast aluminum with white polyester powder finish. Electrical components horizontally opposed and heat-sinked to ballast housing for cooler operation. Integral splice box mounting flange ensures structural integrity.
Self-cleaning ventilated design carries contaminants through the top of the reflector.
High-efficiency, anodized, spun aluminum reflector features exclusive contoured design.
Ballast: All ballasts are 100% factory tested. HPS: Constant wattage autotransformer. MH: 175-450W fixtures shipped within the U.S. require super CWA pulse start ballasts which are 88% efficient and EISA-legislation compliant (must specify SCWA option). CSA, NOM or INTL options required for probe start shipments outside the U.S.
Socket: Vertically oriented mogul base protected exclusionary "PINK" socket with copper alloy, nickel-plated screw shell and center contact.
Pendant splice box: Removable cast-aluminum box slides on integral die-cast aluminum housing mounting flange and mounts to 3/4" pendant conduit prior to ballast housing installation. Matching wire access cover accepts RELOC® modular wiring. Complete assembly meets or exceeds UL 50- pound pull test.
Optic mounting adjustable reflector mounting brackets are progressively die-formed of 18-gauge galvanized steel.
Suggested Replacement Products
Photometry & BIM
Request BIM Files
|Correlated Color Temperature||Not Applicable|
|Light Source||HID - High Pressure Sodium, HID - Metal Halide, Not Applicable|
|Listings||CSA, Not Applicable, UL Damp Location|
|Lumen Output||Not Applicable|
|Mounting Type||Not Applicable|
|Product Type||High Bay|
|Voltage Rating||120, 208, 240, 277, 347, 480, Not Applicable|
