T260L Trac Head

Trac-Master® Wall Wash, Flood LED Trac Head

By Juno

    Energy Star®DLC Standard / PremiumBuy America(n)
  • Overview
  • Specifications
Juno Trac-Master T260L wall-wash/flood LED track fixtures produce up to 5,978 lumens from just 55-watts input, yielding energy-saving efficacies of up to 108 lumens per watt. Installed on Juno Trac-Master™ or Trac-Lites™ track systems, the narrow-profile design permits a greater concentration of fixtures to be placed on the same section of track. Custom hyperbolic reflectors deliver exceptionally uniform, wide beam distributions. The T260L wall-wash/flood fixture provides 360° horizontal rotation and 90° vertical aiming. An assortment of light control accessories is available.
Read More
Read Less
Light Source LED - Static
Lumens 5500 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K
CRI 80, 90, 97
Product Type Track Head
Compliance Listing BAA, DLC Standard, ENERGY STAR®
Dimming Protocol Forward Phase, Reverse Phase
Color Black, Silver, White
Mounting Type Track/Monopoint
Voltage Rating 120
Fixture Wattage 55
Track Mounting Adapter GTYPE, HTYPE, JTYPE, LTYPE
Series T260L

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    SPEC SHEET D1_6_9.pdf T260L Trac-Master® LED Wall Wash, Flood Trac Head 3/29/2022 View
    SPEC SHEET T258LG2-T259LG2-T260L-DIM.pdf T258L G2, T259L G2, T260L, SP258MLL G2, SP259MLL G2, SP260MLL, T258L TEK G2 Dimmer Compatibility View
  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.
  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions P4676_G-Type Adapter.pdf Installation Instructions for G-Type Adapter 8/25/2020 View
    Installation Instructions P4677_H-Type Adapter.pdf Installation Instructions for H-Type Adapter View
    Installation Instructions P4678_L-Type Adapter.pdf Installation Instructions for L-Type Adapters View
    Installation Instructions P6300.pdf JUNO Trac adapter 5/19/2022 View
  • Utility Rebate Search

    To look-up a rebate for this product, please follow the steps below:

    Step 1Enter the Zip Code or Select the State and Utility

    Step 2Ensure that the correct Product Category is selected if there is more than one option

  • Replacement Parts

  • Confidential Documents

  • Marketing Material (e.g. Brochures, Sell Sheets, FAQs, )

    Document Type Document Title Description Updated View
    Brochures Juno Trac-Master LED Wall Wash Brochure.pdf Juno Trac-Master LED Wall Wash Brochure 3/7/2022 View
