TC4RAL 1000LM Housing

LED 4in Round Internally Adjustable Remodel Housing

By Juno

    Energy Star®
  • Overview
  • Specifications
Juno® 4-inch internally adjustable, 1000 lumen LED, non-IC remodel housings cater to a wide range of application possibilities with just a change out of trims. Offering internal adjustability of up to 35° vertical and 360° rotation using the patent pending adjustable light engine modules, light can be directed where needed for downlighting or accent lighting applications. A stunning collection of round and square trims, including downlights, adjustables and lensed along with industry exclusive sloped ceiling trims are easily changed out in the field to adapt to future design needs.
Read More
Read Less
Size 4 IN
Shape Round
Light Source LED - Static
CRI 90
Product Type Housing
Compliance Listing ENERGY STAR®
Environmental Listing Non-IC
Dimming Protocol 0-10V, Forward Phase, Reverse Phase
Mounting Type Recessed
Voltage Rating 120, 120-277
Fixture Wattage 16.6
Series TC4RAL

Read More Read Less

  • Suggested Replacement Products


  • Spec Sheets

    Document Type Document Title Description Updated View
    SPEC SHEET G1_7_63.pdf Juno TC4RAL (10LM) Recessed Housing, Angle Cut Trims 9/15/2020 View
    SPEC SHEET G1_7_64.pdf Juno TC4RAL (10LM) Recessed Housing, Downlight Trims 9/15/2020 View
    SPEC SHEET G1_7_65.pdf Juno TC4RAL (10LM) Recessed Housing, Slot Adjustable Trims 7/18/2019 View
    SPEC SHEET G1_7_66.pdf Juno TC4RAL (10LM) Recessed Housing, Lensed Trims 9/8/2020 View
    SPEC SHEET G1_7_67.pdf Juno TC4RAL (10LM) Recessed Housing, Wall Wash Trims 7/18/2019 View
    SPEC SHEET G1_7_68.pdf Juno TC4RAL (10LM) Recessed Housing, Square Trims 9/15/2020 View
    SPEC SHEET G1_7_69.pdf Juno TC4RAL (07LM) Recessed Housing, Slope Ceiling Trims 9/15/2020 View
    SPEC SHEET JUNOICLED-DIM.pdf Juno 4", 5" and 6" LED Downlight Dimmer Compatibility 3/8/2022 View

    Create Submittal Spec Sheet

  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.
  • Spectral Data Sheets

  • Guideline Specifications

  • BIM Models (Revit)

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions P3774.pdf Juno 4" Remodel Housing Template and Installation Instructions View
    Installation Instructions P4126.pdf Juno 4" Internally Adjustable LED Remodel Recessed Housing Installation Instructions 6/4/2019 View
  • Utility Rebate Search

    To look-up a rebate for this product, please follow the steps below:

    Step 1Enter the Zip Code or Select the State and Utility

    Step 2Ensure that the correct Product Category is selected if there is more than one option
  • Replacement Parts

  • Confidential Documents

  • Marketing Material (e.g. Brochures, Sell Sheets, FAQs, )

    Document Type Document Title Description Updated View
    Brochures Juno 4in Internally Adjustable LED Brochure.pdf IC4AL 4in Juno Downlighting Housing 9/2/2020 View
