ILBLP CP20 HE SD HV Emergency LED Driver

20 Watt Constant Power Low Profile High Voltage Emergency LED Driver
    CA Title 20
  • Overview
  • Specifications
Read More
Read Less
Product Type Emergency LED Driver
Voltage Rating 120-277
Frequency 50/60HZ
Load Voltage Rating 55-200 VDC
Output Power 20 Watts
Max. Operating Temp. 55
Min. Operating Temp. 0
Battery Run Time 90 min
Battery Chemistry Type Lithium Iron Phosphate
Battery Recharge Time 24 hours
Battery Activation AC Activate
Life Safety Testing Self Diagnostics, Self Test
Regulatory Listing C-UL-US, cUL
Compliance Listing CA Title 20, ROHS
Series ILBLP

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    Spec Sheet Copy & Paste Specification Sample Specification for ILBLP CP20 HE SD HV models 7/16/2020
    Spec Sheet ILBLP CP20 HE SD HV Specifications Specification Sheet for the IOTA ILBLP CP20 HE SD HV 5/22/2023 View
    View Product
    View Now
  • Photometry & Revit (BIM)

  • Spectral Data Sheets

  • Guideline Specifications

  • Revit Component Files (Non-Illuminated)

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions A Mounting Style (TBTS Test Switch) ILBLP CP HE SD HV A (Dual Flex) Mounting Style with TBTS Test Switch 5/3/2022 View
    Installation Instructions B Mounting Style (TBTS Test Switch) ILBLP CP HE SD HV B (Integral) Mounting Style with TBTS Test Switch 5/3/2022 View
    Installation Instructions S Mounting Style (TBTS Test Switch) ILBLP CP HE SD HV S (Single Flex) Mounting Style with TBTS Test Switch 5/3/2022 View
    Material Safety Data Sheet MSDS Datasheet for 20W LiFePO Emergency Driver Safety Data Sheet for lithium emergency driver component 5/12/2021 View
    Technical Bulletins Comprensión de la Potencia Constante Maximiza la seguridad en las salidas de emergencia utilizando potencia constante real (CP) 4/12/2021 View
    Technical Bulletins LP Designs with Advanced Lithium Technology How engineering diligence and careful handling helps improve reliability of IOTA ILBLP drivers 6/25/2020 View
    Technical Bulletins The Need for Surge Protection IOTA emergency drivers feature enhanced designs for withstanding exposure to electrical surges. 4/5/2021 View
    Technical Bulletins Understanding Constant Power Understand the benefits of IOTA's patented Constant Power emergency LED driver design 2/11/2022 View
    Wiring Diagram (English) Typical Installation - TBTS PDF Format - Typical Installation with TBTS Test Accessory 5/3/2022 View
    Wiring Diagram (English) Typical Installation - TBTS DWG Format - Typical Installation with TBTS Test Accessory 5/3/2022
    Wiring Diagram (French) Installation Typique - TBTS PDF Format - Installation typique avec accessoire de test TBTS 5/3/2022 View
    Wiring Diagram (French) Installation Typique - TBTS DWG Format - Installation typique avec accessoire de test TBTS 5/3/2022
  • Utility Rebate Search

  • Replacement Parts

  • Confidential Documents

  • Marketing Material (e.g. Brochures, Sell Sheets, FAQs)

    Document Type Document Title Description Updated View
    Application Guide Application Brief for "HV" Emergency Drivers Reference and Comparison Chart for IOTA "HV" Emergency Drivers for non-Class 2 Forward Voltage LEDs 5/20/2020 View
    Application Guide Contractor Insider - Emergency Lumen Output A quick guide on understanding how wattage correlates with emergency lumen output 9/15/2021 View
    Application Guide Contractor Insider - Remote Mounting Guidelines A Quick Reference for knowing remote mounting capabilities of emergency lighting solutions. 10/21/2021 View
    Application Guide ILB CP Lumen Reference Chart Quickly identify IOTA LED Emergency Drivers that meet your desired lumen levels 8/11/2023 View
    Application Guide Tabla de Referencia de Lumen de ILB CP Identifique rápidamente los drivers LED de emergencia de IOTA que cumplen con los niveles de lumen deseados 4/12/2021 View
    Brochures IOTA HE Products for California Title 20 IOTA Emergency Lighting Solutions Certified in the Title 20 Appliance Efficiency Database 7/21/2022 View
    Brochures IOTA Tech Brief: What is AC Activate Understand the key benefits that AC Activate technology brings to the installation process. 2/11/2022 View
    Sell Sheet IOTA-Contractor-Insider_AC-Activate-Explained.pdf How IOTA AC Activate Saves Time and Money on the Jobsite 11/5/2021 View
