AX4 DL Housing

Aculux® LED 4in Round New Construction Fixed Downlight Housing

By Aculux

    Energy Star®CA Title 24/JA8Buy America(n)
  • Overview
  • Specifications
Aculux® 4-inch LED precision downlight luminaires produce up to 3200 lumens while consuming only 12-36 watts. This first in class luminaire has best in class 45 degree visual cut off, allowing the eye to focus on the architecture and not the ceiling plane. Available in both ICAT and non-ICAT configurations with 11 optical distributions capable of providing the precise amount of light for high contrast or uniform downlighting.
Read More
Read Less
Size 4 IN
Shape Round
Light Source LED - Static
Lumens 1200 LM, 1700 LM, 2200 LM, 2700 LM, 3200 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K
CRI 80, 90, 95
Product Type Housing
Compliance Listing BAA, CA Title 24, Chicago Plenum, ENERGY STAR®, JA8
Environmental Listing Damp Location, Wet Location
Regulatory Listing cUL, UL
Dimming Protocol 0-10V, Forward Phase, Forward Phase 2W, Reverse Phase
Fixture Wattage 12, 12.9, 15.6, 17.2, 22.5, 25.1, 29.7, 33.2, 35.6, 36.2
Voltage Rating 120, 277, MVOLT
Trim Style Bevel, Cone, Lensed, Open
Color Black, Clear, Wheat, White
Mounting Type Recessed
Series AX4

Read More Read Less
