Round straight aluminum general purpose pole for up to 30-foot mounting heights.
Shaft: One-piece extruded 6063-T6 aluminum alloy with T6 temper. Circumferential satin-brushed finish. Round straight tube is uniform in cross-section down length of shaft with no taper.
Anchor base: Cast from A356 aluminum alloy and heat treated to T6 temper. Base plate and shaft are circumferentially welded top and bottom. The anchor base is provided with slotted holes.
Anchor bolts: Fabricated from carbon steel bar with minimum-yield strength of 55,000 psi. Bolts have an "L" bend on lower end and are galvanized a minimum of 12 inches on the threaded end per ASTM A-153. Each anchor bolt is furnished with two hex nuts and two flat washers.
Grounding: Provision located inside hand hole rim. Grounding hardware is not included (provided by others).
Hand hole: Reinforced 2" x 4" hand hole is located 18" above base. (4.5" and 5" poles have either 2" x 4" or 3" x 5" hand hole; 6" poles have a 3" x 5" hand hole). Cover and attachment hardware furnished.
Hardware: Stainless steel.
Top cap: Removable top cap provided with drill-mount poles.
Bolt covers: A356 bolt covers included with anchor base unless otherwise specified.
Finish: Must specify finish.
